transducer cable

[Chromeslayer]

i think im getting interference problem through my transducer cable.. i really cant route the cable any other way in the boat... what i would like to know if there is a sheilded tape that i could wrap the cable in.. or any other type of sheilded wire housing?

[gokudl3]

I get interference problems when my trolling motor is on, but only certain speeds (Low-to mid low speed)problems. I wish i new too.

[Diversion]

Do you have your excess cable coiled up? If so, the interferance could be coming from the coil as the signal would be traveling in a circle fashion.

Back some time, I was told to never coil excess transducer cable, but rather run it forward and back along itself so that the excess is running parellel to itself, and not in a circle. I hope that makes sense.

[Chromeslayer]

actually it is coiled up.. i will look into that also.. any other ideas on anyway to sheild it?

[Chromeslayer]

well here let me show u what i got going on..

this pic was taken drifting down the niagara with the main motor off

now i do have the power wire for the sonar ran to the battery, i turned on and off all things that could cause interference.. bilge, livewell, etc.. with no change to the sonar screen.. the ducer is a duel freq.. i was runnin it in the 200khz mode with a 12degree cone.. for some reason i think the 12degree cone is part of my problem in this shallow of water.. i went out to 50fow and the screen got better without really changing any settings.. but in the shallow water im pickin up alot of crap as u can see.. anyone else think its the duel freq ducer? i have a single freq ducer 20degree cone i think im gunna install to see if this helps my problem

[muskybob]

Hey Chromeslayer, if you turn down the sensitivity, do you still have the same problem?

[Chromeslayer]

it was set at 80percent in that shot i beleive.. it does go away when i turn it down.. way down

[muskybob]

Just for the heck of it, try setting it to "auto" & see what happens. Keep us posted.

[Chromeslayer]

auto was the same...

[Tim Bromund]

Chrome, I think Adam probably nailed it. A coiled wire in single loops (circle) creates an electromagnet, which they say can create all sorts of interference problems. Uncoil it and coil it back up in a figure 8 configuration to eliminate that condition ( I use wire zip ties to keep it in the figure eight ).

Tim

[Chromeslayer]

thanks guys.. gunna go tinker with things tomorrow.. then try to get out after some browns this weekend

[ray koziatek]

try the factory reset thing pwr unit off then press pages and power at same time this will get back all factory settings without loosing any saved waypoints or trails...i just did mine this last trip after being on hold for near a hour and talking with a factory rep. the book does say donot coil or run near any other voltage source ,but my slack is coiled up and tied to the wire mess under my dash without any interference ...........hmmmmmm maybe thats why i dont mark any fish.......
